Land surveying is a detailed process that involves comprehensive measurements, calculations, and documentation to define and establish land boundaries. The FMB field measurement book knows it all. One of the critical duties in this field includes the part of a record of the land surveying, land measurement, or any record of the measurements taken in the field. FMB is an important document needed for this purpose. In this blog, you will look into the details of the Field Measurement Book, its purpose, components, and significance in land surveying.
What is an FMB Map?
The Field Measurement Book (FMB Sketch) is a collection of land map data. This is maintained as volume by the government-concerned Village Administrative Officer (VAO) or Revenue Department.
FMB map is the record of measurement, measured according to a scale that can be 1:1000 or 1:2000, and it provides the precise details of the land. An FMB sketch is important because it enables the surveyor to record the measurements for a particular area to make the site plan.
The Role of FMB Map in Land and Property Development
FMB maps facilitate land ownership and buying, selling, or building on land. They help you avoid making mistakes or getting into legal trouble. Let us see how FMB maps are useful for land and property development:
Clear Boundaries
FMB maps display the precise boundaries of your property. This prevents arguments with neighbors or gives confusion over where your land begins and ends.
Helps with Legal Work
If there is a land dispute or you must prove your land size in court, you can present the FMB map as a legal document. It displays official government land measurements.
Tool for Builders and Architects
If you plan to build a house or something, builders and engineers can look at the FMB map to plan accordingly. It guides them on how much land they can use and ensures structures are put up safely.
Support Land Registration and Sale
When selling your land or registering the land in your name, you must submit the FMB map with your property papers. This provides more transparency and trust in the sale process.
Helpful for Loans
Some banks or loan companies may request an FMB map when you apply for a home or land loan. It helps the bank verify that the ground exists and is formally measured.
Prevents Illegal Occupation
If someone else wants to take advantage of your land or build on it without a formal permit, the FMB map can prove ownership, the actual size, and the extent of the land.
Types of FMB MAP
FMB maps have several different types of drawings, with each showing different information.
Profile Sketches
These provide a side view of the land. They show whether the land rises or falls (the slopes).
Plan Drawings
These are all top-down views (like a bird’s-eye view). The plan drawings represent the layout of the land from above and where buildings are located.
Elevation Sketches
These are photographs of the front view of a building or land. They also show the height and outer appearance of buildings.
Components of FMB
G-line
This is a conceptual or reference line used to position and scale the sketch. It helps create triangles with fixed dimensions to determine land parcel boundaries. It serves as a base for calculating offset distances.
F-line
The F-line marks the actual boundary of the surveyed plot on the FMB sketch. It defines the legal and physical limits of the land parcel.
Subdivision Lines
These lines indicate how a survey number is divided into smaller parts or sub-plots. Each subdivision has a unique number (e.g., 123/1, 123/2), and these are often shown in a ladder format in the sketch.
Ladder
The ladder details indicate the actual outline of the FMB graphic. Offset distance from the G-line can deviate to the left or right side. The ladder will be highlighted if there is a deviation left or right at any point.
Extension Lines
An extension line on the FMB sketch will identify and determine the exact direction in which the subject field meets the adjacent field.
Adjacent Field Survey Numbers
These are needed to translate the FMB sketch into D sketches. They can also cross-check other surveys of the area. So, essentially, this allows you to transform FMBs into D sketches and so on .
How to Check FMB?
Step 1: Usually, the Village Administrative Office, Survey Office, or the Revenue Department maintains FMBs. It might be different from where you are from.
Step 2: You either need to call them in person or search for them online and get to them prepared
Step 3: Take a copy of your government ID, like Aadhaar or Passport, to the office. Apart from that, hold a copy of the land ownership document like the sale deed, patta chitta
Step 4: Have the survey number of the proposed land with you. If the survey number of the land is unknown, reach out to a local advocate or land consultant. They are there to help you search for your land’s survey number. Now, go to the government official and ask for a copy of the FMB.
Step 5: You’ll be required to write a request letter to them and probably need to pay a small fee for them to process your application
Step 6: The turnaround time varies from patent office to patent office, depending on the volume of work. When finished, you can see the copy or obtain a copy of the FMB.
How to Read and Interpret an FMB Map
FMB maps are based on lines, numbers, and symbols. Here’s how to read them:
- Property lines: These define where your property begins and ends.
- Land Piece Number: Each plot of land is given a number. It facilitates land search and verification.
- Measurements: These are measurements of how long or wide the land is.
- North sign: A small arrow indicates north to get direction.
- Symbols: Buildings, wells, and roads might have small drawings or labels.
Steps to Obtain an FMB Map for Your Construction Project
FMB sketches are typically acquired offline, although online facilitation is also available. You can still get FMB sketches offline by visiting the concerned Taluk office or the Village Administrative Office.
FMB maps can be obtained in person as follows:
- Proceed to the respective Taluk office or the Village Administrative Office.
- Fix an appointment with the Tahsildar or Village Administrative officer or competent authority.
- Submit the required documents and get the form together with the survey number, owner signature, correct attestation, if appropriate, etc.
- If the request is valid, the FMB record and a unique reference number will be mailed after the authority reviews the application.
- If the application is denied without any unexplained reasons, you can ask the district collector or other relevant higher authority.
Conclusion
FMB is a very crucial document in the process of handling land properties. The records in the FMBs should be accurate, as it can give rise to an incorrect interpretation later. In addition, you can amend any errors in the FMB maps method online and offline.
Nowadays, FMB map extraction and corrections can be applied easily because of the many online and offline facilitations. Please follow the proper channels to get your scam-free FMB maps. Also, check the official government updates for hassle-free courses.
